1. The Java Core Platform API (version 1.0.2)
2. "Object-Relational Databases on the WWW: Design and Implementation", a paper describing, among other things, the design decisions made in the Java Client Library. (Available in postscript, PDF formats.)

In addition, the JCL offers other important features necessary to support Object-Relational DBMSs like PREDATOR. Specifically, the JCL supports:

1. Callback Mechanisms
2. Type Extensibility
3. Interface Extensibility

ServerSite S = new ServerSite("turing.csuglab.cornell.edu", 9700);

ServerSite S = new ServerSite(getCodeBase().getHost(), 9700);

Connection C = new Connection();
try {
  C.open(S);
} catch (java.net.UnknownHostException X) {
  // The supplied host is unknown; did you spell the host's name correctly?
} catch (CannotConnectException X) {
  // The connection could not be established; is this a PREDATOR server?
} catch (ConnectionAlreadyOpenException X) {
  // The connection object is already open; close it first
}

try {
  Query Q = new Query("SELECT R.pic, R.name FROM Renoir R");
} catch (BadQueryException X) {
  // The query is improperly formatted
}

Then, the query can be submitted via a call to processQuery(Query, boolean):

QueryResult R;
try {
  R = C.processQuery(Q, false);
} catch (NoOpenConnectionException X) {
  // The connection must first be opened
} catch (UnterminatedQueryException X) {
  // The previous query was not terminated via a call to endQuery()
}

if (R == null) {
  // There was no result from the query
} else if (R instanceof RecordStreamResult) {
  RecordStreamResult RSR = (RecordStreamResult)R;
  // Process the record stream
} else if (R instanceof UnformattedResult) {
  UnformattedResult UR = (UnformattedResult)R;
  // Process the unformatted result
}

Unformatted Results

UnformattedResult UR = (UnformattedResult)R;
String Text = UR.toString();
System.out.println("Result: " + Text);

It is important to note that the ADT classes are not values. That is to say, the ADT_int object maintained by the JCL is not an integer. Rather, it is a container for information about integers. ADT objects also provide methods to create new DataObjects, which are value objects. For example, the JCL uses the ADT_image object it maintains to create a new ImageObject, which represents an actual image. (A JCL client is never called upon to create new objects; all objects are returned via calls to RecordStreamResult.getNextRecord(SubclassSelector). However, it is important to understand the conceptual distinction between ADT classes and the objects they manage.)

As previously mentioned, the result tuples from queries are arrays of DataObjects. These objects are only minimally functional insofar as their true properties are hidden. The DataObject class defines a single method, toString(ADTMetaInfo), which prints a textual version of the object. For instance, an DoubleObject will print its value, e.g., "3.141592654". (The parameter ADTMetaInfo is mandatory, and is explained below. If this parameter is omitted, the method invoked will be the toString() method of the Java Core Object class, giving unexpected results.)

To exploit hidden functionality of DataObjects, the Java operator instanceof must be used. Although clients may check to see if a specific type has been returned, e.g., an ImageObject, this is not recommended. To permit extensibility, common functionality that data objects offer has been grouped into interfaces, which the data objects can implement. These interfaces include:

1. CallbackObject: The object is capable of calling back to the server for its "full value". (See callbacks for more information.)
2. DisplayObject: The object is capable of displaying itself.
3. MIMETypeObject: The object is a MIME type object; a browser can display it, provided a URL.

DataObject tuple[] = RSR.getNextRecord(null);
for (int i = 0; i < tuple.length; i++) {
  ADTMetaInfo MetaInfo = RSR.getSchema().getAttribute(i).getMetaInfo();
  ADT TypeADT = RSR.getSchema().getAttribute(i).getTypeADT();
  if (tuple[i] instanceof DisplayObject) {
    ((DisplayObject)tuple[i]).display(MetaInfo);
  } else if ((tuple[i] instanceof MIMETypeObject) &&
             (tuple[i] instanceof CallbackObject)) {
    try {
      getAppletContext().
        showDocument(C.getCallbackObjectURL((CallbackObject)Object,
	                                    TypeADT,
	                                    MetaInfo),
		     "Requested Object");
    } catch (Exception X) {
      // Something went wrong
    }
  } else
    System.out.println(tuple[i].toString(MetaInfo));
}

DataObject tuple[] = RSR.getNextRecord(null);
for (int i = 0; i < tuple.length; i++) {
  ADTMetaInfo MetaInfo = RSR.getSchema().getAttribute(i).getMetaInfo();
  ADT TypeADT = RSR.getSchema().getAttribute(i).getTypeADT();
  DataObject Object = tuple[i];
  /*
   * Now MetaInfo is the meta-information object corresponding to
   * Object, which is an object of type TypeADT.
   */
}

When the JCL opens a connection, the database server sends over a list of type names which corresponds to the types supported by the server. Using these names, the JCL queries the web server from which it was loaded for the corresponding ADT classes. So, for example, when the database server sends over the type name "audio", the JCL attempts to load the class "PREDATOR.ADT.ADT_audio". If the load is successful, the client can now work with that type. If not, result values of that type are ignored by the JCL.

Error Handling

1. After opening connections
2. After processing queries
3. After closing connections

In the (hopefully, rare) instance that the JCL experiences an error not caused by faulty use, a InternalError is thrown. If an internal error occurs in your application, please contact PREDATOR support.

Performing Callbacks

If a result DataObject implements the CallbackObject interface, it is a callback object. To access the object's full value, a callback request must be made. For instance, to access the actual image in a result ImageObject, the server must be contacted.

Callback requests occur via HTTP requests. (Interestingly, these requests are made not of a web server, but directly of the PREDATOR server. The database server recognizes HTTP requests as callbacks, decodes them, and serves the required objects.) To create a connection by which the object can be accessed, a URL is necessary. The JCL provides a way to obtain a URL for a CallbackObject through the getCallbackObjectURL(CallbackObject, ADT, ADTMetaInfo) method.

Once the URL is obtained, it can be used in many ways to fetch the "full value". If the object is a MIME type object and is to be displayed, the URL can be handed to the browser, which will display the object. If the object is to be fetched into memory, a java.net.URLConnection can be created, the the stream can be read into an internal array.

Maintaining Interface Extensibility

The JCL accomplishes interface extensibility by forcing each ADT's Java class to export to the system the minimum functionality class (MFC) for objects of that type, so that the data type will operate properly. For instance, the polygon data type specifies that all objects it deals with must at least provide the functionality of the PolygonObject class. Interfaces are free to use any subclass of this class they desire. (The MFC is exported by the method getObjectClass(ADTMetaInfo).)

To implement interface extensibility, interfaces decide on the extended functionality they require from the data types. For instance, in the above example, the interface designer might define an interface as below:

public interface CaliforniaObject {
  public void DrawYourself(CaliforniaMap C);
}

public class CaliforniaPolygon extends PolygonObject implements CaliforniaObject {
  public void DrawYourself(CaliforniaMap C)
  {
    /* ... */
  }
}
