The CS 6120 Course Blog

A Dependently Typed Language

by Christopher Roman

Overview

For this project, we implement the Calculus of Constructions (CoC) by Coquand and Huet, which is a lambda calculus that sits at the top of the Lambda Cube. This means that it includes polymorphism, type level operators, and dependent types. With the Simply Typed Lambda Calculus, terms are only allowed to depend on terms. Polymorphism lets terms depend on types (e.g., generics). Type level operators allow types to depend on types (e.g., list in OCaml). Dependent types allow types to depend on terms. Dependent types are rather uncommon in most programming languages, so I'd suggest reading these notes created by our very own Adrian Sampson for an introduction to how dependent types work.

Ultimately, dependent types allow us to make full use of the Curry-Howard ismorphism; that is, types correspond to logical statements, and programs correspond to proofs of such statements. For example, consider the polymorphic identity function $\Lambda A. \lambda x: a. x$, or written $(\lambda A : *)(\lambda x : A)x$ in CoC. The type of this program is written $[A: *][x: A]A$, which represents the logical statement $\forall A. a \implies a$. By the Curry-Howard isomorphism, the identity function serves as a proof for that statement because it inhabits the corresponding type. Through this, we can write proofs and be assured that they are free of mistakes (or at least moreso than hand-written proofs).

The Calculus of Constructions provides a quite simple type system that allows us to write proofs through programming. Our goal is to implement CoC and show the ability to write some proofs.

My implementation can be found on GitHub. Special thanks to Vincent Imbimbo for talking through and learning with me how CoC worked.

Design

Some of the design decisions about how to write CoC programs came from an existing implementation of CoC. That implementation is well written and good for working with CoC, though it uses a slightly different syntax.

The Grammar

This paper provides a concise grammar for CoC:

This formulation is much simpler to understand than what is presented by Coquand and Huet.

Typing Rules

CoC makes a distinction between contexts and objects. Contexts are products over $*$, that is, terms of the form $[x_1 : M_1] [x_2 : M_2] ... [x_n : M_n] *$. These terms are denoted as $\Gamma$ and $\Delta$. All other terms are considered objects. The typing rules are presented as follows:

There are two typing judgements: one of the form $\Gamma \vdash \Delta$, which means that $\Delta$ is a valid context given the valid context $\Gamma$, and $\Gamma \vdash M : P$, which means that $M$ has type $P$ in the context $\Delta$. Since programs usually start assuming an empty context, we have $\vdash \Gamma$ meaning $\Gamma$ is a valid context, and $\vdash M : N$ meaning that $M$ has type $N$.

Here is an example of a proof derivation for the type of the identity function $(\lambda A : *)(\lambda x : A)x$:

We can see the context is named for good reason: it keeps track of the types of variables. Interestingly, it also doubles as a way to abstract over types. CoC enjoys nice properties like strong normalization.

In addition to the typing rules, we have $\beta$-conversion rules (denoted $P \cong Q$) that essentially provide a way to reduce terms to a normal form. It is also necessary to prove that types are equivalent. The conversion rules can be found on pp.101-102 in Coquand and Huet's paper. With these conversion rules, they introduce a new typing rule that takes advantage of it:

Additions to CoC

To make CoC easier to work with, we make a few additions to the language:

  | LET; UNTYPED; x = ID; EQUALS; t1 = term; IN; p = program
    { Let (Untyped, x, t1, p) }
  | LET; x = ID; EQUALS; t1 = term; IN; p = program
    { Let (Typed, x, t1, p) }
  | THEOREM; x = ID; EQUALS; t = term; WITH; PROOF; proof = term; SEMICOLON; p = program
    { Theorem (x, t, proof, p) }

The first was adding let expressions so that we can write longer, more useful CoC programs. This is especially useful because the language can become very hard to parse by hand very quickly, so breaking it up into let expressions allows us to build bigger abstractions. I added the option to have the term be typed or untyped. I found this useful sometimes when there was a long term that could be replicated across later terms but wasn't a valid expression on its own.

The second was adding a mechanism that allows us to state a theorem (i.e., a type) and give a proof of that theorem (i.e., a program with that type). My implementation will make sure that the proof actually has that type, or else the program will fail. This gives the user a slightly better experience using the language to prove things.

Implementation

I use OCaml for the implementation because pattern matching and functional programming is well suited for language implementation.

For the parser I use a parser generator, namely Menhir, with OCamllex for the lexer. This made the grammar straightforward to implement and extend with new constructs.

The typing judgement of the form $\Gamma \vdash M : P$ is quite simple to implement. I created a function typecheck_term which takes the $\Gamma$ and $M$ and determines what the type $P$ is. The other judgement of the form $\Gamma \vdash \Delta$ is a little different because just matching on $\Gamma$ is insufficient for figuring out what $\Delta$ is. In other words, it is not syntax directed based just on the form of $\Gamma$. Instead, I chose to write a function typecheck_context which takes both $\Gamma$ and $\Delta$ and checks if we can apply the inference rules to derive this statement, instead of directly deriving $\Delta$ just from $\Gamma$.

Substitution was tricky to implement because I didn't use De Bruijn notation at all. Because of this, it seems like there are still some bugs in substitution. This makes writing the programs somewhat more tricky, but I found that if I expected something to typecheck when it really didn't, then I would change some of the variable names so they are not being reused. In addition, because I didn't use De Bruijn notation, I had to make sure I compared terms up to $\alpha$-equivalence when necessary.

It was also tricky to fold $\beta$-equivalence into the typing rules because I didn't know exactly how to deal with some rules like reflexivity, symmetry, and transitivity. I wrote a function beta_equiv that took $\Gamma$ and $M$ and tried to apply a single $\beta$-equivalence rule. Because all terms have a normal form, I kept applying this function until no changes could be made.

Just like ttyped, I created a simple REPL that I used for quick testing to see the reduced value and type of various terms.

Evaluation

For the evaluation, I decided to see what kinds of theorems I could prove from the Coq standard library. I decided to choose theorems from the Logic library, which seemed like one of the simplest libraries. This had definitions for things like True and False (or Top and Bottom respectively), propositional or and and, if and only if, etc. I was able to state and prove a few theorems.

First we can make some definitions that the library does:

let False = [a:*]a in
let True = [a: *][I: a]a in
let not = [A: *][_: A] False in
let sum = (\A: *)(\B: *) [R: *][f: [_: A]R][g: [_: B]R]R in
let or_introl = (\A: *)(\B: *)(\x: A)(\R: *)(\f: [_: A]R)(\g: [_: B]R)(f x) in
let or_intror = (\A: *)(\B: *)(\y: B)(\R: *)(\f: [_: A]R)(\g: [_: B]R)(g y) in
...

These are the same definitions as in Coq, with slightly less elegant syntax, especially because inductive types have to be encoded.

Now here are some proofs about and:

let prod = (\A: *)(\B: *) [R: *] [_: [_: A][_: B]R] R in
let conj = (\A: *)(\B: *)(\x: A)(\y: B)(\R: *)(\f: [_: A][_: B]R)((f x) y) in

Theorem proj1 = [A: *][B: *][_:  ((prod A) B)]A with
    Proof (\A: *)(\B: *)(\p: ((prod A) B))((p A) (\x: A)(\y: B)x);

Theorem proj2 = [A: *][B: *][_:  ((prod A) B)]B with
    Proof (\A: *)(\B: *)(\p: ((prod A) B))((p B) (\x: A)(\y: B)y);

Here, prod represents propositional and, while conj is the constructor which produces a term of that type. Then, Theorem proj1 and proj2 show that $\forall A, B. A \wedge B \implies A$ and $\forall A, B. A \wedge B \implies B$. When we consider these terms as encodings of pairs, proj1 and proj2 are simply the fst and snd functions like in OCaml.

Here are some more proofs relating to "if and only if":

let iff = (\X: *)(\Y: *) ((prod [_: X]Y) [_: Y]X) in

Theorem iff_refl = [A: *]((iff A) A) with
Proof (\A: *)((((conj [_: A]A) [_: A]A) (\x:A)x) (\x:A)x);

let swap = (\A1:*)(\B1:*)(\p1: ((prod A1) B1))
    ( ( ((conj B1) A1)
        (((proj2 A1) B1) p1)
      )
      (((proj1 A1) B1) p1)
    ) in

Theorem iff_sym = [A2: *][B2: *][_: ((iff A2) B2)]((iff B2) A2) with
Proof (\A2:*)(\B2:*)(\A_imp_B2: ((iff A2) B2))
    (((swap [_: A2]B2) [_: B2]A2) A_imp_B2);

iff_refl claims that if and only if is reflexive, while iff_sym claims that it is symmetric. iff_sym was actually a case where bugs in substitution came up, so I just used different names for abstractions/products.

Interestingly, the last two theorems actually took about a second to typecheck, which is quite surprising because Coq can typecheck these terms extremely quickly. This may be because Coq is based on the Calculus of Inductive Constructions, which is quite different from CoC because it introduces universes. This increased expressivity probably allows for faster implementations.

Unfortunately I didn't have more time to try proving more theorems, though the current evaluation shows that at least relatively simple proofs can be proved.

Hardest Parts to Get Right

Two of the hardest things to get right were substitution and $\beta$-equivalence. These were the main reasons why I had bugs in my implementation. Additionally, debugging became extremely difficult as the programs increased in size simply because so many rules were being applied, it was hard to see exactly where things were going wrong. While CoC is a relatively simple language, some of the examples in Coquand and Huet's paper were very hard to follow, like the inter example. This made it more difficult to get an intuitive understanding of how CoC worked.

Further Work

With more time, I would have liked to implement a general framework for creating inductive types in Coc explained by this paper. With my implementation, it is possible to write the encodings for inductive types like natural numbers and pairs, but we must do the encoding by hand. One could also consider giving the language the style of an interactive theorem prover by being able to manipulate proof/program state.

Conclusion

Hopefully this project provides readers with a better understanding of how a dependently typed language like CoC is implemented. It seems that things like System F$\omega$ get a lot of attention and are well understood by many people, but CoC and dependent types aren't as mainstream. Formal verification seems to be increasingly important, so learning CoC may prove to be useful.
