CS 5220

Introduction and Performance Basics

David Bindel

2024-08-27

Logistics

CS 5220

Title: Applied High-Performance and Parallel Computing
Web: https://www.cs.cornell.edu/courses/cs5220/2024fa
When: TR 1:25-2:40
where: Gates G01
Who: David Bindel, Caroline Sun, Evan Vera

Enrollment

https://www.cs.cornell.edu/courseinfo/enrollment
FA24 Add/Drop Announcement

• CS limits pre-enrollment to CS MEng students.
• We almost surely will have enough space for all comers.
• Enroll if you want access to class resources.
• Enrolling as an auditor is OK.
• If you will not take the class, please formally drop!

Prerequisites

Basic logistical constraints:

• Class codes will be in C and C++
• Our focus is numerical codes

Fine if you’re not a numerical C hacker!

• I want a diverse class
• Most students have some holes
• Come see us if you have concerns

Objectives: Performance sense

Reason about code performance

• Many factors: HW, SW, algorithms
• Want simple “good enough” models

Objectives: Learn about HPC

Learn about high-performance computing (HPC)

• Learn parallel concepts and vocabulary
• Experience parallel platforms (HW and SW)
• Read/judge HPC literature
• Apply model numerical HPC patterns
• Tune existing codes for modern HW

Objectives: Numerical SWE

Apply good software practices

• Basic tools: Unix, VC, compilers, profilers, ...
• Modular C/C++ design
• Working from an existing code base
• Testing for correctness
• Testing for performance
• Teamwork

Lecture Plan: Basics

• Architecture
• Parallel and performance concepts
• Locality and parallelism

Lecture Plan: Technology

• C/C++ and Unix fundamentals
• OpenMP, MPI, CUDA and company
• Compilers and tools

Lecture Plan: Patterns

• Monte Carlo
• Dense and sparse linear algebra
• Partial differential equations
• Graph partitioning and load balance
• Fast transforms, fast multipole

Coursework: Lecture (10%)

• Lecture = theory + practical demos
  • 60 minutes lecture
  • 15 minutes mini-practicum
  • Bring questions for both!
• Notes posted in advance
• May be prep work for mini-practicum
• Course evaluations are also required!

Coursework: Homework (15%)

• Five individual assignments plus “HW0”
• Intent: Get everyone up to speed
• Assigned Tues, due one week later

Homework 0

• Posted on the class web page.
• Complete and submit by CMS by 9/3.

Coursework: Group projects (45%)

• Three projects done with partners (1–3)
• Analyze, tune, and parallelize a baseline code
• Scope is 2-3 weeks

Coursework: Final project (30%)

• Groups are encouraged!
• Bring your own topic or we will suggest
• Flexible, but must involve performance
• Main part of work in November–December

Palate Cleanser

Hello, world!

Introduce yourself to a neighbor:

• Name
• Major / academic interests
• Something fun you have recently read or watched
• Hobbies

Jot down answers (part of HW0).

The Good Stuff

The CS&E Picture

Applications Everywhere!

• Climate modeling
• CAD tools (computers, buildings, airplanes, ...)
• Computational biology
• Computational finance
• Machine learning and statistical models
• Game physics and movie special effects
• Medical imaging
• ...

Parallel Computing Essentials

• Need for speed and for memory
• Many processors working simultaneously on same problem
  • vs concurrency (about logical structure vs performance)
  • or distributed systems (coupled but distinct problems, clients and servers are often at different locations)

Why Parallel Computing?

Scientific computing went parallel long ago:

• Want an answer that is right enough, fast enough
• Either of those might imply a lot of work!
• ... and we like to ask for more as machines get bigger
• ... and we have a lot of data, too

Why Parallel Computing?

Today: Hard to get non-parallel hardware!

• How many cores are in your laptop?
• How many in NVidia’s latest accelerator?
• Biggest single-node EC2 instance?

Organizational Basics

• Cores packaged together on CPUs
  • Cores have instruction-level parallelism (e.g. vector units)
• Memory of various types (memory hierarchy)
• Accelerators have similar pieces, organized differently
• CPUs and accelerators packaged together in nodes
• Nodes often connected in racks
• Networks (aka interconnect or fabric) connecting the pieces

How Fast Can We Go?

Speed records for Linpack benchmark

https://www.top500.org

Speed measured in flop/s (floating point ops / second):

• Giga (\(10^9\)) – a single core
• Tera (\(10^{12}\)) – a big machine
• Peta (\(10^{15}\)) – current top 10 machines
• Exa (\(10^{18}\)) – favorite of funding agencies

What do these machines look like?

How Fast Can We Go?

An alternate benchmark: Graph 500

• Data-intensive graph processing benchmark
• Metric is traversed edges per second (TEPS)
• How do the top machines for Linpack and Graph 500 compare?

What do these machines look like?

What HW and How Fast?

• Some high-end machines look like high-end clusters
  • Except custom networks.
• Achievable performance is
  • \(\ll\) peak performance
  • Application-dependent
• Hard to achieve peak on more modest platforms, too!

Parallel Performance in Practice

So how fast can I make my computation?

• Peak \(>\) Linpack \(>\) Gordon Bell \(>\) Typical
• Measuring performance of real applications is hard
  • Even figure of merit may be unclear (flops, TEPS, ...?)
  • Typically a few bottlenecks slow things down
  • And figuring out why they slow down can be tricky!
• And we really care about time-to-solution
  • Sophisticated methods get answer in fewer flops
  • ... but may look bad in benchmarks (lower flop rates!)

See also David Bailey’s comments:

• Twelve Ways to Fool the Masses When Giving Performance Results on Parallel Computers
• Twelve Ways to Fool the Masses: Fast Forward to 2011 (2011)

Example: Reduction

How can we speed up summing an array of length \(n\) with \(p \leq n\) processors?

• Theory: \(n/p + O(\log(p))\) time with reduction tree
• Is this realistic?

Quantifying Parallel Performance

• Starting point: good serial performance
• Strong scaling: compare parallel to serial time on the same problem instance as a function of number of processors (\(p\))

\[\begin{aligned} \mbox{Speedup} &= \frac{\mbox{Serial time}}{\mbox{Parallel time}} \\ \mbox{Efficiency} &= \frac{\mbox{Speedup}}{p} \end{aligned}\]

Barriers

Ideally, speedup = \(p\). Usually, speedup \(< p\).

Barriers to perfect speedup:

• Serial work (Amdahl’s law)
• Parallel overheads (communication, synchronization)

Amdahl’s Law

\[\begin{aligned} p = & \mbox{ number of processors} \\ s = & \mbox{ fraction of work that is serial} \\ t_s = & \mbox{ serial time} \\ t_p = & \mbox{ parallel time} \geq s t_s + (1-s) t_s / p \end{aligned}\]

Amdahl’s law: \[\mbox{Speedup} = \frac{t_s}{t_p} = \frac{1}{s + (1-s) / p} > \frac{1}{s}\]

So \(1\%\) serial work \(\implies\) max speedup < \(100 \times\), regardless of \(p\).

A Little Experiment

Let’s try a simple parallel attendance count:

• Parallel computation: Rightmost person in each row counts number in row.

• Synchronization: Raise your hand when you have a count

• Communication: When all hands are raised, each row representative adds their count to a tally and says the sum (going front to back).

(Somebody please time this.)

A Toy Analysis

Parameters: \[\begin{aligned} n = & \mbox{ number of students} \\ r = & \mbox{ number of rows} \\ t_c = & \mbox{ time to count one student} \\ t_t = & \mbox{ time to say tally} \\ t_s \approx & ~n t_c \\ t_p \approx & ~n t_c / r + r t_t \end{aligned}\]

How much could I possibly speed up?

Modeling Speedup

Student count:

viewof nstudents = Inputs.range(
  [10, 200],
  {value: 100, step: 1}
);

function tserial(n, r)   { return n * 0.3; }
function tparallel(n, r) { return n * 0.3 / r + r * 1.0; }
function speedup(n, r)   { return tserial(n,r) / tparallel(n,r); }

rows = [1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
        12, 13, 14, 15, 16, 17, 18, 19, 20];

data = ({
    "rows" : rows,
    "speedup" : rows.map((r) => speedup(nstudents,r))
})

Plot.plot({
  marks: [
    Plot.lineY(transpose(data), {x: "rows", y: "speedup"})
  ]
})

(Parameters: \(t_c = 0.3\), \(t_t = 1\).)

Modeling Speedup

Mostly-tight bound: \[\mathrm{speedup} < \frac{1}{2} \sqrt{\frac{n t_c}{t_t}}\]

Poor speed-up occurs because:

• The problem size \(n\) is small
• The communication cost is relatively large
• The serial computation cost is relatively large

Some of the usual suspects for parallel performance problems!

Weak scaling?

Things would look better if I allowed both \(n\) and \(r\) to grow — that would be a weak scaling study.

This probably does not make sense for a classroom setting…

Summary: Parallel Performance

Today:

• We’re approaching machines with peak exaflop rates
• But codes rarely get peak performance
• Better comparison: tuned serial performance
• Common measures: speedup and efficiency
• Strong scaling: study speedup with increasing \(p\)
• Weak scaling: increase both \(p\) and \(n\)
• Serial overheads and communication costs kill speedup
• Simple analytical models help us understand scaling

And in case you arrived late

http://www.cs.cornell.edu/courses/cs5220/2024fa/

... and please enroll and submit HW0!
