So far we've been programming as though all pointers between boxes are equally expensive to follow. This turns out not to be even approximately true. Our simple model of how the computer memory works was that the processor generates requests to the memory that include a memory address. The memory looks up the appropriate data and sends it back to the processor. Computers used to work this way, but these days processors are so much faster than memory that something else is needed. A typical computer memory these days takes about 30ns to deliver requested data. This sounds pretty fast, but you have to keep in mind that a 4GHz processor is doing a new instruction every 0.25ns. Thus, the processor will have to wait more than 100 cycles every time the memory is needed to deliver data.
This problem is solved by sticking smaller, faster memory chips in between the processor and the main memory. These chips are caches; a cache keeps track of the contents of memory locations that were recently requested by the processor. Because the cache is much smaller than main memory (hundreds of kilobytes instead of tens or hundreds of megabytes), it can be made to deliver requests much faster than main memory: in tens of cycles rather than hundreds. In fact, one level of cache isn't enough. Typically there are two or three levels of cache, each smaller and faster than the next one out. The primary (L1) cache is the fastest cache, usually right on the processor chip and able to serve memory requests in one–three cycles. The secondary (L2) cache is larger and slower. Modern processors have at least primary and secondary caches on the processsor chip, often tertiary caches as well. There may be more levels of caching (L3, L4) on separate chip.
For example, the Itanium 2 processor from Intel has three levels of cache right on the chip, with increasing response times (measured in processor cycles) and increasing cache size. The result is that almost all memory requests can be satisfied without going to main memory.
These numbers are just a rule of thumb, because different processors are configured differently. The Pentium 4 has no on-chip L3 cache; the Core Duo has no L3 cache but has a much larger L2 cache (2MB). Because caches don't affect the instruction set of the processor, architects have a lot of flexibility to change the cache design as a processor family evolves.
Having caches only helps if when the processor needs to get some data, it is already in the cache. Thus, the first time the processor access the memory, it must wait for the data to arrive. On subsequent reads from the same location, there is a good chance that the cache will be able to serve the memory request without involving main memory. Of course, since the cache is much smaller than the main memory, it can't store all of main memory. The cache is constantly throwing out information about memory locations in order to make space for new data. The processor only gets speedup from the cache if the data fetched from memory is still in the cache when it is needed again. When the cache has the data that is needed by the processor, it is called a cache hit. If not, it is a cache miss. The ratio of the number of hits to misses is called the cache hit ratio.
Because memory is so much slower than the processor, the cache hit ratio is critical to overall performance. For example, if a cache miss is a hundred times slower than a cache hit, then a cache miss ratio of 1% means that half the time is spent on cache misses. Of course, the real situation is more complex, because secondary and tertiary caches often handle misses in the primary cache.
Caches improve performance when memory accesses exhibit locality: reads from memory tends to request the same locations repeatedly, or at least memory locations near previous requests. Computations that exhibit locality will have a relatively high cache hit ratio. Note that caches actually store chunks of contiguous memory (cache lines) rather than individual words of memory. So a series of memory reads to nearby memory locations are likely to mostly hit in the cache. When there is a cache miss, a whole sequence of memory words is requested from main memory at once. This works well because memory chips are designed to make reading a whole series of contiguous locations cheap. The cache records cached memory locations in units of cache lines whose size depends on the size of the cache (typically 4-32 words).
How does this affect us as programmers? We would like to write code that has good locality to get the best performance. This has implications for many of the data structures we have looked at. For example, we talked about how to implement hash tables using linked lists to represent the buckets. Linked lists involve chasing a lot of pointers, which means they have poor locality. A given linked list node probably doesn't even fill up one cache line. When the node is accessed, the whole cache line is fetched from main memory, yet it is mostly not used.
For best performance, you should figure out how many elements can be fit sequentially into a single cache line. The representation of a bucket set is then a linked list where each node in the linked list contains several elements (and a chaining pointer) and takes up an entire cache line. Thus, we go from a linked list that looks like the one on top to the one on the bottom:
Doing this kind of performance optimization can be tricky in a language like SML where the language is working hard to hide these kind of low-level representation choices from you. A rule of thumb, however, is that SML records and tuples are stored contiguously in memory. So this kind of memory layout can be implemented in SML, e.g.:
Enable JavaScript to see code example.
The idea is that the field inuse keeps track of the number of
element fields that are in use. It turns out that scanning down a linked list
implemented in this way is about twice as fast as scanning down a simple
linked list (at least on a 2006 laptop). The reason is locality.
In a language like C or C++, programmers can control
memory layout better and can reap even greater performance benefits
by taking locality into account.
Since hash tables use linked lists, they can typically be improved by the same chunking optimization. To avoid chasing the initial pointer from the bucket array to the linked list, we inline some number of entries in each array cell, and make the linked list be chunked as well. This can give substantial speedup but does require some tuning of the various parameters. Ideally each array element should take occupy one cache line on the appropriate cache level. Best performance is obtained at a higher load factor than with a regular linked list. Other pointer-rich data structures can be similarly chunked to improve memory performance.
A splay tree is an efficient implementation of balanced binary search trees that takes advantage of locality in the incoming lookup requests. Locality in this context is a tendency to look for the same element multiple times, or to look for elements near other elements in the key ordering. A stream of requests exhibits no locality if every element is equally likely to be accessed at each point. For many applications, there is locality, and elements tend to be accessed repeatedly. A good example of an application with this property is a network router. Routers must decide on which outgoing wire to route the incoming packets, based on the IP address in the packets. The router needs a big table (a map) that can be used to look up an IP address and find out which outgoing connection to use. If an IP address has been used once, it is likely to be used again, perhaps many times. Splay trees are designed to provide good performance in this situation.
Importantly, splay trees offer amortized O(lg n) performance; a sequence of M operations on an n-node splay tree takes O(M lg n) time.
A splay tree is a binary search tree. It has one interesting difference, however: whenever an element is looked up in the tree, the splay tree reorganizes to move that element to the root of the tree, without breaking the binary search tree invariant. If the next lookup request is for the same element, it can be returned immediately. In general, if a small number of elements are being heavily used, they will tend to be found near the top of the tree and are thus found quickly.
We have already seen a way to move an element upward in a binary search tree: tree rotation. When an element is accessed in a splay tree, tree rotations are used to move it to the top of the tree. This simple algorithm can result in extremely good performance in practice. Notice that the algorithm requires that we be able to update the tree in place, but the abstract view of the set of elements represented by the tree does not change and the rep invariant is maintained. This is an example of a benevolent side effect, because it does not change the value represented by the data structure.
There are three kinds of tree rotations that are used to move elements upward in the tree. These rotations have two important effects: they move the node being splayed upward in the tree, and they also shorten the path to any nodes along the path to the splayed node. This latter effect means that splaying operations tend to make the tree more balanced.
The simple tree rotation used in AVL trees and treaps is also
applied at the root of the splay tree, moving the splayed node x up to become
the new tree root. Here we have A < x < B < y < C, and
the splayed node is either x or y depending on which direction the rotation is.
It is highlighted in red.
y x / \ / \ x C <-> A y / \ / \ A B B C
Lower down in the tree rotations are performed in pairs so that nodes on the path from the splayed node to the root move closer to the root on average. In the "zig-zig" case, the splayed node is the left child of a left child or the right child of a right child ("zag-zag").
z x
/ \ / \
y D A y
/ \ <-> / \ (A < x < B < y < C < z < D)
x C B z
/ \ / \
A B C D
In the "zig-zag" case, the splayed node is the left child of a
right child or vice-versa. The rotations produce a subtree whose height is less
than that of the original tree. Thus, this rotation improves the balance of the
tree. In each of the two cases shown, y is the splayed node:
z x y
/ \ / \ / \
y D / \ A z (A < y < B < x < z < D)
/ \ -> y z <- / \
A x / \ / \ x D
/ \ A B C D / \
B C B C
See this page for a nice visualization of splay tree rotations and a demonstration that these rotations tend to make the tree more balanced while also moving frequently accessed elements to the top of the tree.
The classic version of splay trees is an imperative data structure in which tree rotations are done by imperatively updating pointers in the nodes. This data structure can only implement a mutable set/map abstraction because it modifies the tree destructively.
The SML code below shows that it is possible
to implement an immutable set abstraction using a version of splay trees. The
key function is splay, which takes a non-leaf node and a key k to
look for, and returns a node that is the new top of the tree. The element whose
key is k, if it was present in the tree, is the value of the
returned node. If it was not present in the tree, a nearby value is in the
node.
Unlike the classic imperative splay tree, this code builds a new tree as it returns from the recursive splay call. And the case of a simple rotation occurs at the bottom of the tree rather than the top.
Enable JavaScript to see code example.
To show that splay trees deliver the promised amortized performance, we define a potential function Φ(T) to keep track of the extra time that can be consumed by later operations on the tree T. The idea is that for any given tree T, there is a function that is that tree's potential. We then define the amortized time taken by a single tree operation that changes the tree from T to T' as the actual time t, plus the change in potential Φ(T')-Φ(T). Now consider a sequence of M operations on a tree, taking actual times t1, t2, t3, ..., tM and producing trees T1, T2, ... TM. The amortized time taken by the operations is the sum of the actual times for each operation plus the sum of the changes in potential: t1 + t2 + ... tM + (Φ(T2)−Φ(T1)) + (Φ(T3) − Φ(T2)) + ... + (Φ(TM) − Φ(TM-1)) = t1 + t2 + ... tM + Φ(TM) − Φ(T1). Therefore the amortized time for a sequence of operations is an underestimate of the actual time by the amount of the drop in the potential function Φ(TM) − Φ(T1) seen over the whole sequence of operations.
The key to amortized analysis is to define the right potential function. Given a node x in a binary tree, let size(x) be the number of nodes below x (including x). Let rank(x) be the binary logarithm of size(x). Then the potential Φ(T) of a tree T is the sum of the ranks of all of the nodes in the tree. Note that if a tree has n nodes in it, the maximum rank of any node is lg n, and therefore the maximum potential of a tree is n lg n. This means that over a sequence of operations on the tree, its potential can decrease by at most n lg n. So the correction factor to amortized time is at most lg n, which is good.
Now, let us consider the amortized time of an operation. The basic operation of splay trees is splaying; it turns out that for a tree t, any splaying operation on a node x takes at most amortized time 3*rank(t) + 1. Since the rank of the tree is at most lg(n), the splaying operation takes O(lg n) amortized time. Therefore, the actual time taken by a sequence of n operations on a tree of size n is at most O(lg n) per operation.
To obtain the amortized time bound for splaying, we consider each of the possible rotation operations, which take a node x and move it to a new location. We consider that the rotation operation itself takes time t=1. Let r(x) be the rank of x before the rotation, and r'(x) the rank of node x after the rotation. We will show that simple rotation takes amortized time at most 3(r'(x) − r(x))) + 1, and that the other two rotations take amortized time 3(r'(x) − r(x)). There can be only one simple rotation (at the top of the tree), so when the amortized time of all the rotations performed during one splaying is added, all the intermediate terms r(x) and r'(x) cancel out and we are left with 3(r(t) − r(x)) + 1. In the worst case where x is a leaf and has rank 0, this is equal to 3*r(t) + 1.
The only two nodes that change rank are x and y. So the cost is 1 + r'(x) − r(x) + r'(y) − r(y). Since y decreases in rank, this is at most 1 + r'(x) − r(x). Since x increases in rank, r'(x) − r(x) is positive and this is bounded by 1 + 3(r'(x) − r(x)).
Only the nodes x, y, and z change in rank. Since this is a double rotation, we assume it has actual cost 2 and the amortized time is
2 + r'(x) − r(x) + r'(y) − r(y) + r'(z) − r(z)
Since the new rank of x is the same as the old rank of z, this is equal to
2 − r(x) + r'(y) − r(y) + r'(z)
The new rank of x is greater than the new rank of y, and the old rank of x is less than the old rank y, so this is at most
2 − r(x) + r'(x) − r(x) + r'(z) = 2 + r'(x) − 2r(x) + r'(z)
Now, let s(x) be the old size of x and let s'(x) be the new size of x. Consider the term 2r'(x) − r(x) − r'(z). This must be at least 2 because it is equal to lg(s'(x)/s(x)) + lg(s'(x)/s'(z)). Notice that this is the sum of two ratios where s'(x) is on top. Now, because s'(x) ≥ s(x) + s'(z), the way to make the sum of the two logarithms as small as possible is to choose s(x) = s(z) = s'(x)/2. But in this case the sum of the logs is 1 + 1 = 2. Therefore the term 2r'(x) − r(x) − r'(z) must be at least 2. Substituting it for the red 2 above, we see that the amortized time is at most
(2r'(x) − r(x) − r'(z)) + r'(x) − 2r(x) + r'(z) = 3(r'(x) − r(x))
as required.
Again, the amortized time is
2 + r'(x) − r(x) + r'(y) − r(y) + r'(z) − r(z)
Because the new rank of x is the same as the old rank of z, and the old rank of x is less than the old rank of y, this is
2 − r(x) + r'(y) − r(y) + r'(z)
≤ 2 − 2 r(x) + r'(y) + r'(z)
Now consider the term 2r'(x) − r'(y) − r'(z). By the same argument as before, this must be at least 2, so we can replace the constant 2 above while maintaining a bound on amortized time:
≤ (2r'(x) − r'(y) − r'(z)) − 2 r(x) + r'(y) + r'(z) = 2(r'(x) − r(x))
Therefore amortized run time in this case too is bounded by 3(r'(x) − r(x)), and this completes the proof of the amortized complexity of splay tree operations.
